AMERICAN TYPE Compact Substation

American type prefabricated box substation is a compact, skid-mounted, fully integrated outdoor power distribution equipment designed according to ANSI and IEEE American standards. Different from European box substations, it adopts an integrated compact structure with transformer, high-voltage fuse, load switch and low-voltage distribution unit highly integrated in one sealed box. It features small footprint, simple structure, convenient installation and strong overload capacity, which is the mainstream power distribution equipment for North America, South America and overseas American-standard power grid projects.

Inquire Now Next Product

Technical Specifications

Model	Capacity (kVA)	Voltage	Grade	Dimension (L×W×H) mm
ZGS-30	30	10kv-0.4kv	IP23/IP44/IP54	1800 × 1200 × 2000
ZGS-50	50			1800 × 1200 × 2000
ZGS-80	80			2000 × 1300 × 2100
ZGS-100	100			2000 × 1300 × 2100
ZGS-160	160			2200 × 1500 × 2200
ZGS-200	200			2200 × 1500 × 2200
ZGS-250	250			2400 × 1600 × 2300
ZGS-315	315			2400 × 1600 × 2300
ZGS-400	400			2600 × 1800 × 2400
ZGS-500	500			2600 × 1800 × 2400

Product Advantages

American Standard Compliance & Strong Compatibility

Ultra-compact & Space-saving Structure

Excellent Sealing & Weather Resistance

Simple Operation & Low Maintenance

Fast On-site Installation & Delivery

Strong Overload & Impact Resistance

Production Process

We adopt standardized American-standard production system and integrated manufacturing process to ensure every box substation meets IEEE and ANSI standard requirements.

High-quality Raw Material Selection

Precision Sheet Metal & Welding Process

Multi-layer Heavy-duty Anti-corrosion Treatment

Standardized Internal Assembly & Wiring

Factory Pre-installation & Pre-commissioning

Testing Process

All American type box substations pass full-item strict testing in accordance with IEEE/ANSI standards to ensure 100% qualified delivery.

Incoming Material Inspection

Box Structural Performance Test

Electrical Performance Full Test

Temperature Rise & Overload Test

Vibration & Transportation Simulation Test

Final Factory Inspection
